CSC5251GSS21
CSC
8704223000
Product Specification for Reference:
| Cabin | HW 76 with a sleeper 70° hydraulically tillable to the front as attached photo for ref. | |
| Vehicle Main Dimensions | (L x W x H)mm | 9900×2500×3250 |
| Wheel base (mm) | 4600+1350 | |
| Wheel track (front/rear) (mm) | 2022/1830 | |
| Approach/Departure angle(°) | 19/27 | |
| Weight in KGS | Tare Weight | 12470kg |
| Loading Capacity | 20000kg | |
| Front axles loading capacity | 1x7000 | |
| Rear axles loading capacity | 2x16000 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Brand | Sinotruk |
| Model | WD615.47 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 371HP | |
| Emission standard | Euro 2 | |
Sewage Tank | Color | As requirements |
Effective Tank Volume | 20000L | |
Tank Thickness | Tank body 6 mm, seal is 8 mm | |
Tank Material | Carbon Steel Q235-B |
Vacuum Pump | Pump brand | Chinese Pump |
Pump model | 65QZXDG-68/400 | |
Rotation speed | 500(r/min) | |
Absolute working pressure | 400Pa (99.6%) | |
Exhaust diameter | 65mm | |
Power | 5Kw |
Suction Pipe | Length(m) | 6 m |
Quantity(pcs) | 2pcs |
| Production Cycle | 45-50 days |
| Warranty | One Year for key parts: engine, gearbox, tank body and pump |
Product Specification for Reference:
| Cabin | HW 76 with a sleeper 70° hydraulically tillable to the front as attached photo for ref. | |
| Vehicle Main Dimensions | (L x W x H)mm | 9900×2500×3250 |
| Wheel base (mm) | 4600+1350 | |
| Wheel track (front/rear) (mm) | 2022/1830 | |
| Approach/Departure angle(°) | 19/27 | |
| Weight in KGS | Tare Weight | 12470kg |
| Loading Capacity | 20000kg | |
| Front axles loading capacity | 1x7000 | |
| Rear axles loading capacity | 2x16000 | |
| Max. driving speed(km/h) | 90 | |
| Engine | Brand | Sinotruk |
| Model | WD615.47 | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 371HP | |
| Emission standard | Euro 2 | |
Sewage Tank | Color | As requirements |
Effective Tank Volume | 20000L | |
Tank Thickness | Tank body 6 mm, seal is 8 mm | |
Tank Material | Carbon Steel Q235-B |
Vacuum Pump | Pump brand | Chinese Pump |
Pump model | 65QZXDG-68/400 | |
Rotation speed | 500(r/min) | |
Absolute working pressure | 400Pa (99.6%) | |
Exhaust diameter | 65mm | |
Power | 5Kw |
Suction Pipe | Length(m) | 6 m |
Quantity(pcs) | 2pcs |
| Production Cycle | 45-50 days |
| Warranty | One Year for key parts: engine, gearbox, tank body and pump |
