Shacman H3000 6x4 Sewage Suction Truck 18000L Vacuum Sewage Suction Tanker Truck for Sale

Shacman H3000 6x4 Sewage Suction Truck 18000L Vacuum Sewage Suction Tanker Truck for Sale
Availability:
Quantity:

PDF Export

whatsapp sharing button
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button
  • Sewage Suction Truck

  • Chusheng

The New Shacman H3000 Vacuum Sewage Suction Truck is a state-of-the-art vehicle specifically designed for efficient septic tank and sewer cleaning operations. Available in both 4x2 and 6x4 configurations, this truck is built to handle the rigors of waste suction and transportation with ease and reliability.


  • Powerful Suction System: Equipped with a high-performance vacuum pump, it provides a strong suction force capable of clearing even the most stubborn blockages.

  • Robust Frame: The truck's chassis is made of high-strength steel to ensure durability and stability during operation.

  • Large Capacity Tank: The sewage tank is spacious, allowing for extended periods of operation without frequent emptying.

  • Hydraulic System: A fully automated hydraulic system controls the suction and discharge processes, enhancing operational efficiency.

  • Safety Valves: Integrated safety valves prevent overflow and ensure safe operation under various conditions.

  • Easy Control: The cab is equipped with an intuitive control panel for easy management of all truck functions.

  • Versatile Applications: Suitable for a wide range of suction tasks, from residential septic tanks to industrial sewer systems.


Applications

  • Septic Tank Cleaning: Ideal for cleaning and emptying septic tanks in residential areas.

  • Sewer System Maintenance: Effective for clearing blockages and sucking out sludge from sewer systems.

  • Industrial Waste Management: Capable of handling industrial waste suction where high suction power is required.

  • Emergency Response: Can be rapidly deployed for emergency spill response and clean-up operations.

  • Suitability for Different Surfaces

  • The truck is designed to operate on various terrains, including urban roads, rural areas, and industrial sites.


Maintenance and Care:

  • Regular Inspection: Routine checks of the suction system, valves, and hydraulic components ensure optimal performance.

  • Tank Cleaning: Post-operation tank cleaning prevents buildup and maintains the truck's hygiene.

  • Hydraulic Fluid Check: Regular checks and changes of hydraulic fluid are crucial for smooth system operation.

  • Tyre Maintenance: Consistent tyre pressure checks and rotations extend tyre life and improve safety.


FAQ:

  1. Q: What is the suction capacity of the SINOTRUK HOWO Vacuum Sewage Suction Truck?

    A: The suction capacity varies based on the model, but our trucks are designed to provide industry-leading performance.


  2. Q: How often should the truck be serviced?

    A: We recommend a thorough service after every 500 hours of operation or as per the manufacturer's guidelines.


  3. Q: Can the truck handle high-viscosity waste?

    A: Yes, the truck is capable of handling high-viscosity waste with its powerful vacuum pump.


  4. Q: Is the truck easy to operate?

    A: Yes, with its user-friendly control panel and automated systems, the truck is designed for ease of operation.


The New SINOTRUK HOWO Vacuum Sewage Suction Truck is a powerful ally for maintaining clean and healthy environments. With its advanced features and robust design, it stands as a reliable choice for professional septic and sewer cleaning services.


Cabin

H3000 with a sleeper
70° hydraulically tillable to the front as attached photo for ref.

Vehicle Main Dimensions

(L x W x H)mm

9900×2500×3250

Wheel base (mm)

4600+1350

Wheel track (front/rear) (mm)

2022/1830

Approach/Departure angle(°)

19/27

Weight in KGS

Tare Weight

12470kg

Loading Capacity

20000kg

Front axles loading capacity

1x9500

Rear axles loading capacity

2x16000

Max. driving speed(km/h)

90

Engine

Brand

Weichai

Model

WP12.400E201

Type

4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling

Horse Power(HP)

400 HP

Emission standard

Euro 2

Gearbox

10JSD180, 10 forwards & 2 reverse

Clutch

Reinforced diaphragm clutch, diameter 430mm Clutch

Fuel tank (L)

400

Tire

12.00R20 tubeless tire , 11 pieces including 1 spare

Sewage Tank

Color

As requirements

Effective Tank Volume

18000L

Tank Thickness

Tank body 6 mm, seal is 8 mm

Tank Material

Carbon Steel Q235-B

Vacuum Pump

Pump brand

Chinese Pump

Pump model

65QZXDG-68/400

Rotation speed

500(r/min)

Absolute working pressure

400Pa (99.6%)

Exhaust diameter

65mm

Power

5Kw

Suction Pipe

Length(m)

6 m

Quantity(pcs)

2pcs

Production Cycle

45-50 days

Warranty

One Year for key parts: engine, gearbox, tank body and pump

Our Advantage

1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as original manufacturer
3.Products Quality Certification SGS CCC ISO TUV
4.Perfect after-sale service
5.Customized products are available as per clients' requirements
6.Export to more than 60 countries and regions

Warranty

1. One year quality guarantee for three key parts axles, engine, transmission or within 50000km, which comes the first.

2. Other spare parts could be supplied by OEM at factory cost prices.
3. Regularly follow up to know the vehicle's working status.
4. Free technical support during the whole life cycle of the truck and trailers (say 10 years);

5.Special service team with technial engineers are ready if any quality complains, will respond in 24 hours with feedback and solution.


Flexible Payment Term:

1.100% TT

2. 30% TT in advance,70% before shipment

3. 100% USANCE LC at sight

4. TT in advance, balance in LC


Delivery time:

30-40 working days after receipt of advance deposit

Packing and Shipping:

Nude and wax, shipped in container ship, bulk vessel, flat deck or RO-RO ship
(1)Wax:
Do wax spray process to against the trailer body suffer seawater corrosion during shipping
(2)Package:
Stable fixing with steel wire,to protect the trailer during shipping
(3)Shipping:
Reliable logistic service from famous freight supplier makes transport process safely and promptly
