CSC2023091201
CSC
8705909990
Features
Modular Design: Allows for easy cleaning and modification to suit different types of livestock.
Ventilation System: Ensures proper air circulation to maintain a healthy environment for the animals.
Hydraulic Ramps: Facilitates easy loading and unloading of animals.
Non-Slip Flooring: Provides a safe surface for the animals to stand on during transport.
Temperature Control: Some models include climate control systems to regulate the temperature inside the truck.
Safety Partitions: Divides the cargo area into compartments to prevent overcrowding and stress among animals.
Applications
Poultry and Livestock Transportation Trucks are used in various scenarios:
Farm to Slaughterhouse: Transporting animals for processing.
Breeding Facilities: Moving animals for breeding purposes.
Market Transportation: Carrying animals to and from livestock markets.
Veterinary Services: Transporting animals to veterinary clinics for treatment or check-ups.
Agricultural Shows and Fairs: Moving animals for exhibition or competition.
Categories and Uses
Poultry Trucks: Specifically designed with features like tiered racks to transport chickens, ducks, or other poultry.
Cattle Trucks: Equipped with sturdy partitions and ample space for larger animals like cows and bulls.
Sheep and Goat Trucks: Designed to accommodate the specific needs of these smaller livestock.
Horse Transporters: Spacious interiors with ramps or hydraulic lifts for the safe transport of horses.
Multi-Species Transporters: Versatile trucks that can be configured for various types of animals.
Maintenance and Care
Proper maintenance is crucial for the longevity and reliability of a Poultry and Livestock Transportation Truck:
Regular Cleaning: Thoroughly clean the truck after each use to prevent the buildup of waste and bacteria.
Inspection of Ramps and Partitions: Check for any damage or wear that could affect the safety of the animals.
Ventilation System Check: Ensure the ventilation system is functioning properly to provide adequate airflow.
Hydraulic System Maintenance: Regularly check the hydraulic systems for leaks and proper operation of ramps and lifts.
Tire Care: Maintain appropriate tire pressure and inspect for wear to ensure safe transportation.
Lubrication: Keep moving parts well-lubricated to prevent friction and wear
Features
Modular Design: Allows for easy cleaning and modification to suit different types of livestock.
Ventilation System: Ensures proper air circulation to maintain a healthy environment for the animals.
Hydraulic Ramps: Facilitates easy loading and unloading of animals.
Non-Slip Flooring: Provides a safe surface for the animals to stand on during transport.
Temperature Control: Some models include climate control systems to regulate the temperature inside the truck.
Safety Partitions: Divides the cargo area into compartments to prevent overcrowding and stress among animals.
Applications
Poultry and Livestock Transportation Trucks are used in various scenarios:
Farm to Slaughterhouse: Transporting animals for processing.
Breeding Facilities: Moving animals for breeding purposes.
Market Transportation: Carrying animals to and from livestock markets.
Veterinary Services: Transporting animals to veterinary clinics for treatment or check-ups.
Agricultural Shows and Fairs: Moving animals for exhibition or competition.
Categories and Uses
Poultry Trucks: Specifically designed with features like tiered racks to transport chickens, ducks, or other poultry.
Cattle Trucks: Equipped with sturdy partitions and ample space for larger animals like cows and bulls.
Sheep and Goat Trucks: Designed to accommodate the specific needs of these smaller livestock.
Horse Transporters: Spacious interiors with ramps or hydraulic lifts for the safe transport of horses.
Multi-Species Transporters: Versatile trucks that can be configured for various types of animals.
Maintenance and Care
Proper maintenance is crucial for the longevity and reliability of a Poultry and Livestock Transportation Truck:
Regular Cleaning: Thoroughly clean the truck after each use to prevent the buildup of waste and bacteria.
Inspection of Ramps and Partitions: Check for any damage or wear that could affect the safety of the animals.
Ventilation System Check: Ensure the ventilation system is functioning properly to provide adequate airflow.
Hydraulic System Maintenance: Regularly check the hydraulic systems for leaks and proper operation of ramps and lifts.
Tire Care: Maintain appropriate tire pressure and inspect for wear to ensure safe transportation.
Lubrication: Keep moving parts well-lubricated to prevent friction and wear
Cabin | Single row with one sleeper cab | |
Vehicle Main Dimensions | (L x W x H)mm | 8390×2550×2890 |
Wheel base (mm) | 4500 | |
Wheel track (front/rear) (mm) | 2022/1830 | |
Approach/Departure angle(°) | 19/27 | |
Weight in KGS | Tare Weight | 8390kg |
Loading Capacity | 10000kg | |
Front axles loading capacity | 1x6500 | |
Rear axles loading capacity | 1x11500 | |
Max. driving speed(km/h) | 90 | |
Engine | Brand | Yuchai |
Model | YC6L240N-52 | |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
Horse Power(HP) | 240HP | |
Emission standard | Euro 5 | |
Gearbox | 6 forwards & 1 reverse | |
Clutch | Reinforced diaphragm clutch, diameter 430mmClutch | |
Steering Gear | ZF 8098,power steering, hydraulic steering with power assistance | |
Fuel tank (L) | 120 | |
Tire | 10.00R20 18PR All radial tire is available , 7 pieces with 1spare | |
Brakes | Service brake: dual circuit compressed air brake | |
Carriage | Floors | 3 |
Front/side | 3mm in high tensile strength steel Q345/B | |
Bottom | 4mmin high tensile strength steel Q345/B | |
Size | 6300x2550x1790 mm |
Cabin | Single row with one sleeper cab | |
Vehicle Main Dimensions | (L x W x H)mm | 8390×2550×2890 |
Wheel base (mm) | 4500 | |
Wheel track (front/rear) (mm) | 2022/1830 | |
Approach/Departure angle(°) | 19/27 | |
Weight in KGS | Tare Weight | 8390kg |
Loading Capacity | 10000kg | |
Front axles loading capacity | 1x6500 | |
Rear axles loading capacity | 1x11500 | |
Max. driving speed(km/h) | 90 | |
Engine | Brand | Yuchai |
Model | YC6L240N-52 | |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
Horse Power(HP) | 240HP | |
Emission standard | Euro 5 | |
Gearbox | 6 forwards & 1 reverse | |
Clutch | Reinforced diaphragm clutch, diameter 430mmClutch | |
Steering Gear | ZF 8098,power steering, hydraulic steering with power assistance | |
Fuel tank (L) | 120 | |
Tire | 10.00R20 18PR All radial tire is available , 7 pieces with 1spare | |
Brakes | Service brake: dual circuit compressed air brake | |
Carriage | Floors | 3 |
Front/side | 3mm in high tensile strength steel Q345/B | |
Bottom | 4mmin high tensile strength steel Q345/B | |
Size | 6300x2550x1790 mm |
Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as original manufacturer
3.Products Quality Certification SGS CCC ISO TUV
4.Perfect after-sale service
5.Customized products are available as per clients' requirements
6.Export to more than 60 countries and regions
Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 50000km, which comes the first.
2. Other spare parts could be supplied by OEM at factory cost prices.
3. Regularly follow up to know the vehicle's working status.
4. Free technical support during the whole life cycle of the truck and trailers (say 10 years);
5.Special service team with technial engineers are ready if any quality complains, will respond in 24 hours with feedback and solution.
Flexible Payment Term:
1. 100% TT
2. 30% TT in advance,70% before shipment
3. 100% USANCE LC at sight
4. TT in advance, balance in LC
Delivery time:
30-40 working days after receipt of advance deposit
Packing and Shipping:
Nude and wax, shipped in container ship, bulk vessel, flat deck or RO-RO ship
(1)Wax:
Do wax spray process to against the trailer body suffer seawater corrosion during shipping
(2)Package:
Stable fixing with steel wire,to protect the trailer during shipping
(3)Shipping:
Reliable logistic service from famous freight supplier make
Our Advantage
1.Competitive Factory Price and Excellent Quality
2.More than 20 years' experience as original manufacturer
3.Products Quality Certification SGS CCC ISO TUV
4.Perfect after-sale service
5.Customized products are available as per clients' requirements
6.Export to more than 60 countries and regions
Warranty
1. One year quality guarantee for three key parts axles, engine, transmission or within 50000km, which comes the first.
2. Other spare parts could be supplied by OEM at factory cost prices.
3. Regularly follow up to know the vehicle's working status.
4. Free technical support during the whole life cycle of the truck and trailers (say 10 years);
5.Special service team with technial engineers are ready if any quality complains, will respond in 24 hours with feedback and solution.
Flexible Payment Term:
1. 100% TT
2. 30% TT in advance,70% before shipment
3. 100% USANCE LC at sight
4. TT in advance, balance in LC
Delivery time:
30-40 working days after receipt of advance deposit
Packing and Shipping:
Nude and wax, shipped in container ship, bulk vessel, flat deck or RO-RO ship
(1)Wax:
Do wax spray process to against the trailer body suffer seawater corrosion during shipping
(2)Package:
Stable fixing with steel wire,to protect the trailer during shipping
(3)Shipping:
Reliable logistic service from famous freight supplier make
1,Hubei Chusheng Vehicle Co.,Ltd is a renowned and the largest manufacturer in the field of special-purpose vehicles in China for over 20 years. We have more than 3,000 workers and 400 technical personnel, with a factory size exceeding 690,000 square meters.
2,Our products have been exported to 60 countries, including regions and countries in the Middle East, Asia, Africa, and Eastern Europe. Our products have passed the ISO 9001 quality system certification and CCC certification.
3,Our company has over 1,000 units of advanced production equipment, forming production lines for dump trucks, tanker trucks, tow trucks, garbage trucks, and other special trucks and semi-trailers, with an annual production capacity of 50,000 units.
1,Hubei Chusheng Vehicle Co.,Ltd is a renowned and the largest manufacturer in the field of special-purpose vehicles in China for over 20 years. We have more than 3,000 workers and 400 technical personnel, with a factory size exceeding 690,000 square meters.
2,Our products have been exported to 60 countries, including regions and countries in the Middle East, Asia, Africa, and Eastern Europe. Our products have passed the ISO 9001 quality system certification and CCC certification.
3,Our company has over 1,000 units of advanced production equipment, forming production lines for dump trucks, tanker trucks, tow trucks, garbage trucks, and other special trucks and semi-trailers, with an annual production capacity of 50,000 units.
