New JMC Mini Truck 1 Ton 1.5ton 2.5 Ton Capacity Diesel Flatbed Cargo Truck

Availability:
Quantity:

PDF Export

whatsapp sharing button
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

Small and light dump trucks are lightweight and flexible, making it easy to deliver goods through streets and alleys, and have always been the preferred model for urban delivery.


Product Feature:

  • JMC cargo truck chassis
    The rear axle adopts a small cargo truck rear axle and is equipped with dual tires, so the load-bearing performance is guaranteed.


  • JMC Carrying Plus new single row cab
    The interior adopts a single row cabin-style layout. Although it is a small cargo truck, the overall depth of the space gives the driver and passengers enough enjoyment.


  • Steering wheel and display
    The left and right steering wheels can be customized according to customer needs. The cab has multimedia functions and is equipped with air conditioning. The two-ring instrument is combined with the LCD screen in the middle to facilitate reading of real-time

    vehicle data.


    Product Advantage:

    1. With its small size, small trucks can travel more quickly and quickly through some urban and rural roads, and there is no need to worry about turning or U-turning when driving into narrow alleys.

     2. Transporting goods with small weight and volume can be regarded as a subdivided product in the light vehicle market. For the transportation of small goods, it can still make the best use of it.

    3. The three side panels of small trucks can be opened for easy loading and unloading. 1. Small trucks have low fuel consumption and extremely high cost performance. They are the preferred models that cannot be missed in the process of urban distribution transportation.


JMC New Carrying Truck Specifications
Payload2.5T
ModelFrigo
CabinSingle
Gross Vehicle Weight (kg)3490
Payload (kg)2500
Seat Capacity2
Wheelbase (mm)2490
Tread Front (mm)1395
Tread Rear (mm)1375
Min.Ground Clearance (mm)185
Min.Turning Diameter (m)104
Max.Gradeability (%)28
Max.Speed (km/h)100
Fuel Consumption (L/100km)8
Fuel Tank60L
EngineJX493Q1
Gear BoxMSB-5M
Displacement (cc)2771
Compression Ratio18:2:1
Max.Torque (N·m/rpm)172/2000
Max.Output (km/hp/rpm)57(77)/3600
Outside Size (L*W*H)(mm)4880×1720×2750
Rear Body Size (L*W*H)(mm)3060×1565×1730
Tubeless Tyre6.50R16


HUBEI CHUSHENG VEHICLE CO., LTD. has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high-quality service for our customers, we train every salesman with the necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.

Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customers.
3. Provide unique and professional solutions based on customer's requirements.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visits and so on.

In-sale service:
1. Tracking report in producing.
2. Quality test report for every order.
3. Photos and videos as per customer's requirement.
4. Free spare parts.

After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint response period not exceeding 24 hours; maintenance guidance and problem solutions supplied in 48 hours.
3. Customer satisfaction tracking report.
4. Free technician training.
5. Full set of documents free of charge, which includes installation guidance, software operation manual, easy maintenance manual control system software CD and so on.
6. Special service for big projects, such as stadiums, exhibitions, squares and so on.
